GE circuit breaker selection for real panel conditions

Match system voltage, continuous current, poles, trip curve, available fault current, interrupting capacity and mounting interface before approving a replacement or new feeder device. Our project desk keeps the known ratings, open checks and requested documentation together from inquiry through quotation.

120–600 V AC15–1200 A10–100 kAIC1–4 poles

Compare Breaker Families

Talk to a Project Specialist

Start with the electrical duty, then prove the interface

Review group	Required inputs	Why it matters
System	Rated voltage, frequency, phase and grounding arrangement	Defines the insulation and application boundary.
Protection	Continuous current, load type, trip curve and selective coordination objective	Separates conductor protection from nuisance-trip risk.
Fault duty	Available fault current and required interrupting capacity or SCCR	A breaker rating must meet the installation duty under applicable rules.
Mechanical	Frame, poles, mounting, terminal orientation and enclosure clearance	An electrically similar breaker is not automatically a physical replacement.

Published example ranges are screening references, not a claim that every catalog number covers every value. Final ratings, listings and accessories must be verified on the exact series documentation.

Protection priorities change with the distribution system

Panel builders

Confirm feeder duty, bus SCCR, wire range, accessory voltage and enclosure space before releasing drawings.

Commercial facilities

Balance maintainability, selective coordination and arc-flash objectives across service and branch equipment.

OEM machinery

Review motor loads, control power, destination standards and replacement access inside compact control panels.

Water and process plants

Account for motor starting, humid environments, downtime constraints and documented lockout practices.

Build a circuit breaker request that engineering can review

Send the existing catalog number, readable label photo, single-line diagram, system voltage, load current, available fault current, poles, mounting style, accessory requirements, quantity and destination. Unknown values can remain marked as unknown so the next measurement or document request is explicit.

Selection and replacement cross-reference assistance

Series-level trip curves, drawings and listing documents

Quote, availability and delivery coordination
